Energy & Range
Capacity63 kWh
City range395 km
Highway range345 km
City consumption15.9 kWh/100km
Hwy consumption18.3 kWh/100km
Charging
AC charge11 kW
DC charge (peak)90 kW
10→90% AC4h 35min
10→90% DC35 min
Battery warranty8 yr
Battery
ChemistryNMC
Cell formatCATL prismatic NMC
ArchitectureAiways EV platform
Pack voltage400V
Aiways U5 — Battery Overview
The Aiways U5 (2022) is a C-segment suv electric vehicle with a 63 kWh NMC battery. It delivers up to 395 km city range and 345 km on the highway.
DC fast charging peaks at 90 kW, completing 10→90% in approximately 35 min. AC charging at 11 kW takes around 4h 35min for the same charge level. City energy use is 15.9 kWh/100km. 63 kWh usable, CATL NCMA.
NMC: Nickel Manganese Cobalt — high energy density, longer range
VoltEV — EV Battery Database. Data for reference only.
